Bilstein 25-187595 5160 Series Shock Absorber (1994-2012 Dodge Ram 3500 4WD (Front) Lifted 0"-3" )

Designed as a direct fit replacement for your lifted 1994-2013 Dodge Ram 2500 or 1994-2012 Dodge Ram 3500, the Bilstein 25-187595 5160 Series Shock Absorber provides a smooth and comfortable ride. The 5160 Series Shock Absorber features a remote reservoir that increases cooling capacity and wheel travel for an optimized performance. A special monotube design provides the 5160 Series Shock Absorber with a consistent performance and features velocity sensitive digressive valve settings which are tuned for each specific application. Every 5160 Series Shock Absorber features a unique 360-degree swivel banjo hose fitting which results in a clean, low-profile installation.

Specifications:

• Series: 5160 Series
• Drive Type: 4WD
• Position: Front
• Lifted Height: 0”-3”
• Quantity Needed Per Vehicle: 2
• Finish: Zinc Plated
• Reservoir: Yes
• Body Design: 46mm Smooth Body (Non-Coilover)

Measurements:

• Collapsed Length: (IN) 15.20
• Extended Length: (IN) 25.96
• Collapsed Length: (MM) 386.0
• Extended Length: (MM) 659.5

Applications:

• 2006-2008 Dodge Ram 1500
• 1994-2010 Ram 2500
• 1994-2010 Ram 3500
• 2011-2013 Ram 2500
• 2011-2012 Ram 3500
